We are able to present a wide variety of 350 Double Disc Grinder Machine. It is fabricated with a premium grade of materials which are sourced from a genuine vendors of a market. This machine is mainly used for industrial applications. In addition to this, provided machine requires very less maintenance and power consumption. 350 Double Disc Grinder Machine is helpful to avoid coolant entry. It is easy to operate and managed without making any efforts.
Technical Specification
Aspects |
Unit |
Dimension |
Grinding wheel diameter |
mm |
350 |
Gap between grinding wheels |
mm |
1.50 |
Quill adjustment travel, each time |
mm |
50 |
Grinding wheel Dimensions |
mm |
350 OD x 110 ID x 55 width |
Power requirement total |
kw |
8.6 |
Approx |
hp |
11.75 |
Net weight approx |
kg |
1200 |
Work piece diameter |
mm |
10.00 |
Work piece thickness |
mm |
1.50 to 50 |
Maximum error in parallelism |
mm |
0.005 |
Maximum error in flatness |
mm |
0.005 |
